BEST DEAL
৳7,500
Longi Horizon LR5-28HTH-225M Solar Panel Price in Bangladesh
0.0 (0)
· 15 available
Brand:
7 Days easy return
Standard Delivery
Delivery time: 6-10 days
৳ 100
Sylhet City Delivery
৳ 60
Warranty
Vouchers
More Voucher ›
VOUCHER MAX
7% OFF
Upto ৳ 30 Off
LIMITED
10% OFF
Min. Spend ৳ 1550
SE MART BD
bKash
Wallet payment
Sold by
Inhouse product
Ratings & Reviews (0)
0.0
There have been no reviews for this product yet.
Please Login to submit a review
Sold by
SEMartBD.Com | SE mart online shopping
(0 reviews)
Top Selling Products
Longi Horizon LR5-28HTH-225M Full Specification
Item Solar Panel
Model Longi Horizon LR5-28HTH-225M
Cell Type Monocrystalline Silicon
Number of Cell 56
Front Glass Single glass, 3.2mm coated tempered glass
Maximum Power 225W
Maximum Power Voltage 17.24V
Maximum Power Current 13.06A
Short Circuit Current 14.10A
Open Circuit Voltage 20.50V
Module Efficiency 21.6%
Maximum System Voltage DC 1500V
Connector Mc4 Compatible
Operating Temperature 0.050%/℃
Weight 12.1kg
Dimension 1354 x 767 x 30mm
- Operating Parameters
- Power Output Tolerance: 0 ~ 3%
- Maximum Series Fuse Rating: 22A
- Nominal Operating Cell Temperature: 45±2℃
- Protection Class: Class II
- Fire Rating
- UL type 1 or 2
- IEC Class C
- Temperature Ratings (STC)
- Temperature Coefficient of Isc: +0.050%/℃
- Temperature Coefficient of Voc: -0.230%/℃
- Temperature Coefficient of Pmax: -0.280%/℃
- Mechanical Parameters
- Junction Box: IP68
- Output Cable: 4mm2, ±1200mm length can be customized
Glass - Frame: Anodized aluminum alloy frame
Overview
This Longi Horizon LR5-28HTH-225M Monocrystalline 225W solar panel is a high-efficiency, half-cut cell design product. The front glass is single glass, 3.2mm coated tempered glass. The half-cut technology increases the panel's performance by reducing resistive losses. It comes with 56 (4x14) cells and 225W, making it suitable for residential and commercial applications. Moreover, the frame of this solar panel is made of aluminum alloy, which is durable and ensures long-term service.
