SMD Sine Wave Inverter Kit With LCD Display

SMD SINEWAVE (LCD BASED)

Salient features :

1. Microcontroller based design with DSP technology.

2. Pure Sine Wave output

3. SMPS based battery charger, charges battery from 130V onwards (no sound from transformer)

4. Fuzzy Logic multi – stage battery charger

5. Charging Current 8.5 – 10 Amp

6. Complete overload and short circuit protection with capability to run highly inductive loads

7. Automatic overload reset

8. Closed loop regulated Sine Wave output from no load to full load

9. Changeover time less than 10 M sec in home UPS mode

10. Line synchronized change over

11. Soft start inverter mode for cold starting inductive loads

12. Compact design with minimum components. Easy to repair and maintain

LCD Display

When Grid Power Present

Displays – AC Voltage , Battery Charging status , Battery level , Mode

In back up

Displays – Back up mode On/off, Battery level , Load level in %,

Fault Conditions

Displays- Battery low , Overload , Short cicuit, Mains Failure,

Fuse blown, Temperature high, no load.
